Lifting Machine Double Girder Overhead Crane With Ground Operation
Double-girder bridge cranes have many uses and are widely used in real life. In many factories, many product manufacturers choose cranes for easy handling, and single-girder bridge cranes are more prominent in terms of helping transportation.
The double-beam crane has the advantages of compact appearance, light weight, low wheel pressure, stable running speed, low noise, and convenient installation and maintenance. It is suitable for use in warehouses, workshops, power stations and other places where there is no electricity and no source of electricity.
In addition to general machinery workshops, single-beam bridge cranes are widely used in workshops, warehouses, and material yards such as petroleum and petrochemical, railway construction, civil aviation airports, hydroelectric power stations, ports, papermaking, building materials, metallurgy, etc.
| Mechanism | Item | Unit | Result |
| Item | | |
| Lifting capacity | ton | 1-30ton |
| Working grade | | A3-A5 |
| Span | m | 7.5-31.5m |
| Working environment temperture | °C | -25~40 |
| Travelling mechanism | working speed | m/min | 20-75 |
| motor | type | | ZDY1 21-4 | ZDR 100-4 |
| power | kw | 2*0.8 | 2*1.5 |
| rotational speed | m/min | 1380 |
| Lifting mechanism | lifting speed | m/min | 8/0.8(7/0.7) 3.5(3.5/0.35) 8(7) |
| lifting height | H(m) | 6 9 12 18 24 30 |
| travelling speed | m/min | 20 30 |
| working system | A3-A5 |
| power source | three-phase 380V 50HZ |
5 ton single beam overhead crane with best price is widely used in plants,warehouses,material stocks to lift godds. It is prohibited to use the equipment in the combustiblle,explosive or corrosives enviroment.
The capacity:1-30ton
The span : 7.5-31.5m
The working grade : A3-A5
The working temperature:-25℃ to 40℃
